On-Chip Memory
On-Chip Memory is the smallest size data storage product. It's suitable for the application of limited space, low power consumption. The BGA packaged memory products supports data security and industrial-grade environment. And the eMMC flash offers memory system at a low cost.
Overview
On-Chip Memory is the smallest size data storage product. It's suitable for the application of limited space, low power consumption. The BGA packaged memory products supports data security and industrial-grade environment. And the eMMC flash offers memory system at a low cost.
Specification：
|
|
RS20 series | RS50 series | OS10 series | 0S20 series | RN10 series |
| Basic Infomation |
|
||||
| Form Factor | BGA104 |
BGA310 |
BGA313 |
BGA313 | BGA307 |
| Interface |
SATA Ⅲ (SATA Ⅱ& SATA Ⅰ COMPATIBLE) |
SATA Ⅲ (SATA Ⅱ& SATA Ⅰ COMPATIBLE) |
SATA Ⅲ (SATA Ⅱ& SATA Ⅰ COMPATIBLE) |
SATA Ⅲ (SATA Ⅱ& SATA Ⅰ COMPATIBLE) |
PCIe 3.0×4 NVMe 1.4 |
| Dimension(mm) | 14.0×18.0×1.8 |
30.0x20.0x2.75 |
31.0x36.0x3.0 |
31.0×36.0×3.0 | 30.0×35.0×3.0 |
| Flash | SLC/MLC/TLC |
PSLC/TLC |
SLC/MLC |
PSLC/TLC |
pSLC/TLC |
| Capacity |
SLC: 8GB,16GB,32G MLC: 16GB,32GB,64GB
TLC:128GB,256GB
|
pSLC: 32GB,64GB,128GB TLC: 128GB,256GB,512GB |
SLC: 128GB,256GB,512GB MLC: 128GB,256GB,512GB
|
pSLC: 64GB,128GB,256GB TLC: 256GB,512GB,1TB
|
pSLC: 64GB,128GB,256GB TLC: 256GB,512GB,1TB |
| Temperature |
|
||||
| Operating Temperature | 1:-20°C~70°C/W:-40°C~85°C/S:-55°C~ 85°C | ||||
| Storage Temperature | -55℃ ~ 95℃ | ||||
| Performance |
|
||||
| Sequential Read | 560MB/s |
560MB/S |
560MB/s |
560MB/s | 2500MB/s |
| Sequential Write | 450MB/s |
500MB/S |
520MB/S |
520MB/s | 2100MB/s |
| Random Read(4K) IOPS | 50K IOPS |
50K IOPS |
73K IOPS |
58KIOPS | 80K IOPS |
| Random Write(4K) IOPS | 25K IOPS |
35K IOPS |
69K IOPS |
40K IOPS | 40K IOPS |
| Reliability |
|
||||
| MTBF | 2,000,000hrs | ||||
| Temperature | 5% ~ 95%(No condensing) | ||||
| Electrical |
|
||||
| Power Supply | 3.3V、1.8V(±5%） |
3.3V(±5%) |
3.3V, 1.8 1.5V,1.2V(士5%) |
3.3V(±5%) | 3.3V(±5%） |
| Power Consumption |
Active≤1.6W
Idle≤0.4W
|
Active≤2W
Idle≤0.5W
|
Active≤4.5W
Idle≤1W
|
Active≤3.2W
Idle≤1.4W
|
Active≤5.6W
Idle≤1.8W
|
| Optional Functions |
|
||||
| Secure Erase | √ |
√ |
√ |
√ | √ |
| Quick Erase | √ |
√ |
√ |
√ | √ |
| Physical Destruction | / | ||||
Applications：
